4.5V to 26V VDD Operating Range, 28V ABS  MAX

Input Pins Can Tolerate -7V to +28V, and are  Independent of Supply Voltage Range

Operating Switching Frequency up to 1MHz

MD18611 provides 4A Source and 8A Sink  Output Peak Currents

MD18617 provides 4A Source and 4A Sink  Output Peak Currents

Less than 10ns Rise and 5ns Fall Time with  2.2nF Load for MD18611

Less than 10ns Rise and Fall Time with 2.2nF  Load for MD18617

Fast Propagation Delay (11ns Typical)

TTL and CMOS Compatible Inputs

Industry-standard-compatible Pinout

Specified from -40°C to 140°C
