AEC-Q100 Grade 1

Meets the ISO 11898-2:2016 and ISO 11898- 5:2007 physical layer standards •

Support classic CAN and 5 Mbps CAN FD

EMC performance: supports SAE J2962-2 and  IEC62228-3 (up to 500 kbps) without common  mode choke

I/O Voltage range supports 3.3 V and 5 V MCUs

Ideal passive behavior when unpowered

Protection features

– Bus Fault protection: ±70 V

– Under-voltage protection on VCC and VIO (V variants only) supply terminals

– Driver dominant time out (TXD DTO)

– Data rates down to 10 kbps

Thermal shutdown protection (TSD)

Receiver common mode input voltage: ±30 V

Typical loop delay: 110 ns

Junction temperatures from –40°C to 150°C
