Integrated 8.5mΩ 100V Power MOSFET

Operates in a wide output voltage range  down to 3V voltage (self-supply)

Self-supply for operations with low-side  rectification and high–side rectification  without an auxiliary winding

10ns Fast Turn-off and 25ns Turn-on Delay

VG Clamping Circuit Works Well when VCC  is Below 2V

Supports CCM, DCM and QR Operations

Precise 0V turn off for maximum efficiency

Designed for <200kHz working frequency
