Optimized for <1MHz Frequency

Supports DCM, QR and CCM Operations

Supports Active Clamp Flyback with GaN  FET or Super-junction MOSFET at Primary Side

Operates in a Wide Output Voltage Range  Down to Zero Voltage

Self-supply for Operation with Low Output  Voltage and/or High–side Rectification  without an Auxiliary Winding

Gate Drive Voltage is Up to 9V

10ns Fast Turn-off and 25ns Turn-on Delay

VD/HVIN Pin Supports Negative Voltage  Spikes Down to -3V

Avoids Potential False Turn-on during DCM

VG Clamping Circuit Works Well when VCC  is Below 2V

Supports both High-side and Low-side  Rectification

Adaptive Gate Drive for Maximum Efficiency
